Magnetic Locks Auto Sliding

RD02001 - AUTO SLIDING MAG LOCK Magnetic Locks Auto Sliding

RD02001 - AUTO SLIDING MAG LOCK

RD02001 -  AUTO SLIDING MAG LOCK Magnetic Locks Auto Sliding
Radiant auto slide door magnetic lock has been specifically designed for automatic sliding door applications where the size of common locking mechanisms create installation difficulties.. Hoisting design,saves time and power when installation. Complete set of accessories available for auto slide lock. Special Anti-residual magnetic design makes automatic access control safer and more convenient.

Model

RD02001 : Magnetic Lock for Auto-sliding Door

SPECIFICATION

Voltage

 AC110V / AC220V

Current Draw

 50mA/AC110V, 25mA/AC220V

Holding Force

 about 80KG / 175LBS

Input Signal

 Remote control, digital keypad, proximity card reader, push button, or any electronic access device.

Output Signal

 Signal will trigger NO type relay which will in turn activate motor to open sliding door.

With lock sensor


RD02001 -  AUTO SLIDING MAG LOCK pdf Download Technical Datasheet RD02001 - AUTO SLIDING MAG LOCK
