Magnetic Locks Water-Proof

RDGL600 SERIES 600 LBS WATERPROOF LOCKS Magnetic Locks Water-Proof

RDGL600 SERIES 600 LBS WATERPROOF LOCKS

RDGL600 SERIES 600 LBS WATERPROOF LOCKS Magnetic Locks Water-Proof
Radiant single door waterproof outdoor gate lock,specially used to out glass door,wooden door,metal door,fire doors,and all kinds of door.Hoisting design,saves time and power when installation.Inward door,frame-less glass door,narrow door all have a complete set of accessories.Special Anti-residual magnetic design makes automatic access control safer.

For outdoor use (water-proof) - all inner components are well sealed and be protected from environmental damages.
Three meters long power cable for convenient installation
Horizontal or vertical installation

SPECIFICATION

Stainless steel housing

Built-in voltage spike suppressor

Holding Force

 600LBS

Voltage

 12V/24VDC (Selectable)

Current Draw

 500mA/12V , 250mA /24V

Special Finish

 Zinc (on the magnet & armature plate)


RDGL600 SERIES 600 LBS WATERPROOF LOCKS pdf Download Technical Datasheet RDGL600 SERIES 600 LBS WATERPROOF LOCKS
