Magnetic Locks Shearlock

RDM01 - MAGNETIC SHEARLOCK- 1200 LBS Magnetic Locks Shearlock

RDM01 - MAGNETIC SHEARLOCK- 1200 LBS

RDM01 - MAGNETIC SHEARLOCK- 1200 LBS Magnetic Locks Shearlock
Radiant shear lock offers the advantage of a totally concealed locking mechanism, providing superior security and appearance while allowing for normal door movement. The patented design incorporates locking tabs on the magnet assembly with mating grooves in the armature plate. Superior hold force with advanced microprocessor controlled electronic features including auto sensed voltage, auto re-locking, adjustable re-lock time delay and options for integrating into an access control system.

In-swing/Out-swing door/Double action door
Adjustable door status position for improved security

SPECIFICATION

Black Painted bracket

Built-in voltage spike suppressor

Holding Force

 1200LBS

Voltage

 12V/24VDC (Selectable)

Signal

Lock status sensor (Hall), Timer

Current Draw

 1.6A/12VDC, 0.3A /24VDC

Special Finish

 Zinc (on the magnet & armature plate)


RDM01 - MAGNETIC SHEARLOCK- 1200 LBS pdf Download Technical Datasheet RDM01 - MAGNETIC SHEARLOCK- 1200 LBS
