Electric Strikes & Bolts Electric Bolt - Fail Safe

RD14203 - Fail Safe Electric Bolt Electric Strikes & Bolts Electric Bolt - Fail Safe

RD14203 - Fail Safe Electric Bolt

RD14203 - Fail Safe Electric Bolt Electric Strikes & Bolts Electric Bolt - Fail Safe
Electric Bolts provide electrical locking of a door by driving bolt into the strike preventing the door from opening. They are a comparatively simple means of locking a door electronically, and provide a great level of security with low level power usage.

Suitable for double swing door
With lock and Door status sensor
Built-in voltage spike suppressor
Use jumper to select auto-lock time delay (0, 2.5, 6 sec.)
Round plate type: easy to make appropriate installation holes

SPECIFICATION

Fail-safe

 Locked when energized

Face plate Material

 Aluminium

Cover plate

 Stainless Steel

Weight

 0.9KGS

Voltage

 12VDC

Current Draw

 Puli-in : 1A / 12VDC

Holding

 0.3A / 12VDC

RD14203 - Fail Safe Electric Bolt pdf Download Technical Datasheet RD14203 - Fail Safe Electric Bolt
