RD14201 - Fail Safe Electric Bolt

RD14201 - Fail Safe Electric Bolt -Intelligent Auto Relock Electric Strikes & Bolts Electric Bolt - Fail Safe
Electric Bolts provide electrical locking of a door by driving bolt into the strike preventing the door from opening. They are a comparatively simple means of locking a door electronically, and provide a great level of security with low level power usage.

Suitable for double swing door
Intelligent Auto-Relock
With lock and Door status sensor
Built-in voltage spike suppressor
Use jumper to select auto-lock time delay (0, 2.5, 5 sec.)
Round plate type: easy to make appropriate installation holes

SPECIFICATION

Request to EXIT

 The lock has 2 wires for remote release

Fail-safe

 Locked when energized

Face plate

 Aluminium

Cover plate

 Stainless steel

Weight

 0.9KG

Voltage

 12VDC or 24VDC

Current

 0.9A / 12VDC , 0.5A/24VDC

Standby

 0.2A / 12VDC , 0.1A/24VDC


RD14201 - Fail Safe Electric Bolt pdf Download Technical Datasheet RD14201 - Fail Safe Electric Bolt
